Sideshifting no-arm Clamps for Forklift

Features

Proven durable T-beam arm aluminium frame construction
Excellent operation field for vision.
Regenerative hydraulic valving for optional arm speed
Superior arm-slide bearing for extended service life

Specification

Capacity@Load Center

(kg@mm)

Catalog Order No.

Mounting

Class

Opening Range

O

(mm)

Arm Pad Size

WxHxT

(mm)

Frame Width C(mm)

Vertical Center of Gravity VCG(mm)

Weight

(kg)

Effective Thickness ET(mm)

Horizontal Center of Gravity HCG(mm)

1600@600

CNR20D-004A

II

410-1655

127x565x40

940

335

454

226

127

2300@600

CNR30D-005A

II

465-1810

125x625x45

1015

335

536

241

142

2300@600

CNR30D-005B

III

465-1810

125X65X45

1015

335

554

279

188

Note

1.Obtain the actual capacity of the forklift and attachments from the forklift manufacturer.
2.Two sets additional oil circuit and magnetic valve required on forklift.
3.Opening range refers to inside spacing of arm base of clamp arm.
4.We can design and manufacture various types of special clamp arm according to user's condition requirements.
5.Please contact the sales from HUAMAI

Hydraulic Flow & Pressure

ModelMin.Hydraulic Flow(L/min)Rec. Hydraulic Flow(L/min)Max.Hydraulic Flow(L/min)Min. Hydraulic Pressure(Bar)Max. Hydraulic Pressure(Bar)
CNR20D20406035160
CNS30D20404035160

Rotator Specification

ModelRotator SpeedRotator Torque
CNR20D5.2r/min@57L/min9000N.M@160Bar
CNR30D5.2r/min@57L/min9000N.M@160Bar

Options

Various mounting classes available
Custom opening ranges

Application

No arm clamps is a kind of clamping device that isn't equipped with clamp arm ,only have the clamp arm base . Users can make special clamp arm according to your special needs ,just welding it on no arm clamp then can be used.

Quick Details

Place of Origin: Fujian, China (Mainland)
Brand Name: HUAMAI
Model Number: CNR30D-005A
Product Name: No-arm clamps for forklift
Type: CNR30D-005A
Mounting Class: II
Opening Range: 465-1810mm
Arm Pad Size WxHxT (mm): 125x625x45mm
Frame Width C(mm): 1015mm
Weight (kg): 536kg
Effective Thickness(mm): 241mm
Horizontal Center of Gravity (mm): 142mm
Vertical Center of Gravity CGV (mm): 335mm
