 Type CRL8 access load shipping container ramp

Type: CRL8 Container Load Ramp


With a 3.0 metres overall length (1.5 metres of which is horizontal) this style allows easy placement and removal of the first and second line of pallets in a container. Fork pockets are provided either side of the ramp, along with flip-up front brackets. Securing chains both side prevent unintentional disengagement of the ramp from the container.

SPECIFICATIONS


Model

 Size

Long x Wide x High (ground to ramp deck)

Capacity

SWL (KG)

Unit Weight

 (KG)

Surface Treatment

CRL8

3000*2320*160

8000

600

Enamel Paint Finish

Quick Details


Place of Origin: Fujian, China (Mainland)
Brand Name: HUAMAI
Model Number:CRL8
Product Name: Shipping container ramp
Type: CRL8
Size( Long x Wide x High): 3000*2320*160
SWL (kg): 8000kg
Unit Weight (kg): 600kg
Load Centre (mm): 1400mm


Introduction]

HUAMAI container ramp is designed to allow your forklift access into standard shipping containers from ground level, as well as be used for vehicles loading from a raised dock. We typically supplied in 6500Kg or 1000Kg capacities to suit your operations, though others are available on request.

HUAMAI  container ramps are greatly appreciated in the markets based on the high quality and reliable performance.

Features:

*The self-leveling lip can be folded so that you can move or store the container ramp more conveniently.

*It’s allows for full load capacity when on slightly uneven ground.

*The back of container ramp is strengthened by steel to make sure the safety when it be used under rated working load.

*The Container ramp can be moved by pallet truck or forklift through the holes.

*The lip of this ramp sits in the container, and is secured in place with locking legs.
