Forklift Tyre Handling Attachment Telescopic Tyre Clamps

Features


Vulcanized rubber pads design, economically.
Excellent operation field for vision.
Regenerative hydraulic valving for optional arm speed
Superior arm-slide bearing for extended service life
Can extend1.2 meters, it more flexible and can handle tyre more efficently.

Specification


CapacityModelMount ClassRoll Range(mm)Mounting angleLong Arm Length

(mm)

Short Arm Length

(mm)

Long Arm Thickness

(mm)

Contact Pad size WxH

(mm)

Effective Thickness

(mm)

Horizontal Center of Gravity

(mm)

2000PTR20F-002AII630-13000 degree82557045300x1500197282
2000PTR20F-002BIII630-13000 degree82557045300x1500237320
2000PTR20F-004AII530-15000 degree95577595300x1500197280
2000PTR20F-004BIII530-15000 degree95577595300x1500237304
2000PTR20F-005A/BII/III630-16000 degree95577595300x1500183/216301
2000PTR20F-007BIII680-18300 degree1130930115300x1500239445
2000PTR20F-008BIII380-18300 degree1130930115300x1500239445

Note


Obtain the actual capacity of the forklift and attachments from the forklift manufacturer.
Two sets additional oil circuit required on forklift.
The total height of holding tire is more than 1/2 clamp pad height,and can't exceed the clamp pad height.
Please contact the sales from HUAMAI

Hydraulic Flow & Pressure


ModelMin.Hydraulic Flow(L/min)Rec. Hydraulic Flow(L/min)Max.Hydraulic Flow(L/min)Min. Hydraulic Pressure(Bar)Max. Hydraulic Pressure(Bar)

PTR20F

20

40

60

35

160

PTR30F

20

40

60

35

160

PTR40F

20

40

60

35

160

Rotator Specification


ModelRotator SpeedRotator Torque
PTR20F5.2r/[email protected]/min[email protected]
PTR30F5.2r/[email protected]/min[email protected]
PTR40F4.1r/[email protected]/min[email protected]

Options


Custom opening ranges
Positioned short arm or fixed short arm

Application


Telescopic Tyre Clamps are suitable for all kinds of tyre handling ,loding an stacking operation ,widely used in to tire industry.

Quick Details


Place of Origin: Fujian, China (Mainland)
Brand Name:HUAMAI
Model Number: PTR20F-004B
Product Name: Telescopic Tyre Clamps
Type: PTR20F-002A
Mounting Class: II
Roll Range(mm): 630-1300mm
Long Arm Length(mm): 825mm
Short Arm Length(mm): 570mm
Long Arm Thickness(mm): 45mm
Effective Thickness(mm): 197mm
Horizontal Center of Gravity (mm): 282mm
Contact Pad size WxH (mm): 300x1500mm
